TP-LINK 4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router

Product Details

Reference KILTPLR4G0020

In stock 22 Items

Data sheet

Mac operating systems supported

Yes

Linux operating systems supported

Yes

Windows operating systems supported

Yes

Package type

Box

Number of products included

1 pc(s)

Width

229 mm

Height

37 mm

Depth

160 mm

Product type

Tabletop router

Package depth

223 mm

Package height

70 mm

Package width

307 mm

Power source type

AC, DC

Cables included

LAN (RJ-45)

Storage relative humidity (H-H)

5 - 90%

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

10 - 90%

Storage temperature (T-T)

-40 - 70 °C

USB port

No

LED indicators

LAN, Power, WLAN

AC adapter included

Yes

4G

Yes

Wi-Fi standards

Wi-Fi 4 (802.11n)

SIM card type

MicroSIM

3G

Yes

Output voltage

12 V

Output current

1.5 A

Ethernet LAN (RJ-45) ports

4

5G

No

DC-in jack

Yes

Networking standards

IEEE 802.11b

Security algorithms

128-bit WEP

Detachable antenna(s)

Yes

Ethernet LAN data rates

1000 Mbit/s

Ethernet LAN

Yes

AC input voltage

100 - 240 V

AC input frequency

50 - 60 Hz

Wi-Fi band

Dual-band (2.4 GHz / 5 GHz)

Antennas quantity

2

Quick installation guide

Yes

Quality of Service (QoS) support

Yes

Supported network protocols

IPv4, IPv6

DHCP client

Yes

Firewall

Yes

Firewall security

Domain Filter, IP, MAC Address Binding

Reset button

Yes

DHCP server

Yes

Wall mountable

No

Product colour

Black

Harmonized System (HS) code

85176990

Parental control

Yes

Top Wi-Fi standard

Wi-Fi 5 (802.11ac)

Mobile network generation

4G

4G standard

LTE

3G bands supported

2100 MHz

3G standards

UMTS

4G bands supported

700

Dual SIM support

No

SIM card slot

Yes

Memory card slot(s)

No

Ethernet LAN interface type

Gigabit Ethernet

WPS push button

Yes

Filtering

Yes

WLAN data transfer rate (first band)

867 Mbit/s

WLAN data transfer rate (second band)

300 Mbit/s

Ethernet WAN

Yes

Wi-Fi Multimedia (WMM)/(WME)

Yes

Warnings

Do not dismantle the unit yourself, there is a risk of electric shock.

DMZ support

Yes

Port forwarding

Yes

Guest access

Yes

DoS attack prevention

Yes

Stateful Packet Inspection (SPI)

Yes

Dynamic DNS (DDNS)

Yes

Port triggering

Yes

Number of guest networks (2.4 GHz)

1

WLAN data transfer rate (max)

867 Mbit/s

Universal Plug and Play (UPnP)

Yes

Antenna design

External

3G/4G USB modem compatibility

No

DSL WAN

No

WAN connection type

RJ-45

Routing protocols

IP

URL filtering

Yes

Number of guest networks (5 GHz)

1
