Prekė detaliau
Charakteristikos
- Package type
- Box
- Width
- 190 mm
- Height
- 318 mm
- Depth
- 630 mm
- Weight
- 27.5 kg
- Package height
- 200 mm
- Package width
- 600 mm
- Number of batteries supported
- 6
- Cables included
- Input power cable, Output power cable, USB cable
- Manual
- Yes
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 20 - 95%
- Form factor
- Rackmount/Tower
- USB port
- Yes
- Battery capacity
- 9 Ah
- Battery recharge time
- 3 h
- Output power
- 3000 W
- Input frequency
- 40/70 Hz
- USB 2.0 ports quantity
- 1
- Display type
- LCD
- Ethernet LAN (RJ-45) ports
- 1
- Input operation voltage (min)
- 110 V
- Output power capacity
- 3 kVA
- Output operation voltage (max)
- 240 V
- Waveform
- Sine
- AC outlet types
- C19 coupler
- Input operation voltage (max)
- 300 V
- Battery voltage
- 12 V
- Output operation voltage (min)
- 200 V
- UPS topology
- Double-conversion (Online)
- Modem (RJ-11) ports
- 1
- Typical backup time at full load
- 3 min
- Warranty card
- Yes
- Typical backup time at half load
- 10.1 min
- Surge protection
- Yes
- Output voltage regulation
- 1%
- RS-232 ports
- 1
- Serial interface type
- RS-232
- Noise Level
- 50 dB
- Power plug
- C14 coupler
- Product colour
- Black
- Harmonized System (HS) code
- 85078000
- Serial interface
- Yes
- Output voltage Total Harmonic Distortion (THD)
- 2%
- Power factor
- 0.99
- Surge protection features
- Modem
- Crest factor
- 3:1
- Emergency Power Off (EPO)
- Yes
- Resource CD
- Yes
- Number of type F outputs
- 9
- Emergency Power Off (EPO) connector
- Yes
- Input current Total Harmonic Distortion (THD)
- 1.6%
- Warnings
- Do not disassemble the unit housing, there may be a risk of electric shock.
Greitas palyginimas
Prekė |
UPS RACK POWERWALKER VFI 1000 LICR IOT PF1 ON-LINE 1000VA 8X IEC C13 USB-B RS-232 LCD 2U
|
APC Smart-UPS SMT1000RMI2UC - 4x C13, USB, Rackmount 2U, SmartConnect, 1000VA
|
APC SRV2KRIRK uninterruptible power supply (UPS) Double-conversion (Online) 2 kVA 1600 W
|
Eaton 9E2000IR uninterruptible power supply (UPS) Double-conversion (Online) 2 kVA 1800 W 6 AC outlet(s)
|
Prieinamumas |
|
|
|
|
Kaina |
1 073,28 €
|
1 079,15 €
|
1 080,93 €
|
1 082,29 €
|
Aprašymas |
||||
Width |
432 mm | 437 mm | 438 mm | |
Height |
86 mm | 86 mm | 86.5 mm | |
Depth |
477 mm | 462 mm | 608 mm | |
Weight |
22.5 kg | 18.2 kg | 29.9 kg | |
Package height |
251 mm | |||
Package width |
594 mm | |||
Number of batteries supported |
1 | 6 | ||
Power source type |
AC | |||
Cables included |
RS-232, USB cable | Output power cable, USB cable | ||
Storage relative humidity (H-H) |
0 - 95% | 0 - 95% | ||
Manual |
Yes | |||
Operating temperature (T-T) |
0 - 40 °C | 0 - 40 °C | 0 - 40 °C | |
Operating relative humidity (H-H) |
0 - 95% | 0 - 95% | 0 - 96% | |
Storage temperature (T-T) |
-15 - 45 °C | -20 - 50 °C | ||
Form factor |
Rackmount | Rackmount | Tower | |
USB port |
Yes | Yes | Yes | |
LED indicators |
Yes | Yes | Yes | |
Battery technology |
Sealed Lead Acid (VRLA) | Lead-acid | ||
Battery life (max) |
6 year(s) | |||
Battery capacity |
7 Ah | |||
Control type |
Buttons | |||
Battery recharge time |
3 h | |||
Output power |
700 W | 1600 W | 1800 W | |
Input frequency |
50/60 Hz | 40/70 Hz | 40/70 Hz | |
USB 2.0 ports quantity |
1 | |||
Response time |
10 ms | |||
Display type |
LCD | LCD | LCD | |
Ethernet LAN (RJ-45) ports |
1 | |||
Efficiency |
91% | |||
Input operation voltage (min) |
151 V | 160 V | 140 V | |
Cold start |
Yes | |||
AC outlets quantity |
4 AC outlet(s) | 6 AC outlet(s) | ||
Output power capacity |
1 kVA | 2 kVA | 2 kVA | |
Output operation voltage (max) |
240 V | 240 V | 240 V | |
Waveform |
Sine | Sine | Sine | |
Auto-restart |
Yes | |||
AC outlet types |
C13 coupler | C13 coupler | ||
Input operation voltage (max) |
302 V | 280 V | 276 V | |
Audible alarm(s) |
Yes | Yes | ||
Battery voltage |
12 V | |||
Output operation voltage (min) |
220 V | 220 V | 220 V | |
UPS topology |
Line-Interactive | Double-conversion (Online) | Double-conversion (Online) | |
Typical backup time at full load |
4.5 min | |||
Automatic Voltage Regulation (AVR) |
Yes | |||
Automatic battery test |
Yes | Yes | ||
Typical backup time at half load |
12 min | |||
Surge protection |
Yes | |||
Nominal input voltage |
230 V | |||
Nominal output voltage |
230 V | |||
RS-232 ports |
1 | |||
Operating altitude |
0 - 3000 m | 0 - 3000 m | ||
Serial interface type |
RJ-45 | RS-232 | RS-232 | |
Quick installation guide |
Yes | Yes | ||
Output frequency |
50/60 Hz | 50/60 Hz | 50/60 Hz | |
Web-based management |
Yes | |||
Noise Level |
45 dB | 45 dB | ||
Serial ports quantity |
1 | 1 | ||
Surge energy rating |
459 J | 600 J | ||
Power plug |
C14 coupler | C13 coupler | ||
Non-operating altitude |
0 - 15000 m | 0 - 14763.6 m | ||
Product colour |
Black | Black | Black | |
Harmonized System (HS) code |
85078000 | 85078000 | ||
Sustainability certificates |
Green Premium | |||
Sustainability compliance |
Yes | |||
Heat dissipation |
546 BTU/h | |||
Battery weight |
20.7 kg | |||
Serial interface |
Yes | Yes | Yes | |
ECO mode |
Yes | |||
USB port type |
USB Type-A | |||
Output voltage Total Harmonic Distortion (THD) |
5% | 3% | ||
Hot-swap battery |
Yes | |||
Compliance certificates |
RoHS | RoHS | CE | |
Total carbon footprint (kg of CO2e) |
1165.17 | |||
Temperature voltage compensation |
Yes | |||
SmartSlot |
Yes | Yes | ||
Replacement battery cartridge |
APCRBC132 | |||
Rack capacity |
2U | 2U | ||
Resource CD |
Yes | |||
Rack mount kit |
Yes | Yes | Yes | |
Output power factor |
0.9 | |||
Input power factor |
99 | |||
Number of input phases |
1 | |||
Number of output phases |
1 | |||
Battery width |
55.1 cm | |||
Battery depth |
59.9 cm | |||
Battery height |
14.2 cm | |||
Efficiency (ECO mode) |
96.5% | |||
