Prekė detaliau
Charakteristikos
- Width
- 196 mm
- Height
- 342 mm
- Depth
- 416 mm
- Weight
- 25.4 kg
- Package height
- 342 mm
- Package width
- 294 mm
- Manual
- Yes
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 20 - 90%
- USB port
- Yes
- Battery capacity
- 9 Ah
- Battery recharge time
- 4 h
- Output power
- 2700 W
- Input frequency
- 40 - 70 Hz
- Ethernet LAN (RJ-45) ports
- 1
- Number of battery cells
- 6
- Input operation voltage (min)
- 80 V
- AC outlets quantity
- 4 AC outlet(s)
- Output power capacity
- 3000 kVA
- Output operation voltage (max)
- 240 V
- Waveform
- Sine
- AC outlet types
- Type E / F
- Input operation voltage (max)
- 300 V
- Battery voltage
- 12 V
- Output operation voltage (min)
- 208 V
- UPS topology
- Double-conversion (Online)
- Output frequency regulation
- 0.5 Hz
- Output voltage regulation
- ± 1%
- Serial ports quantity
- 1
- Product colour
- Black
- Power factor
- 0.9
- Emergency Power Off (EPO)
- Yes
- Emergency Power Off (EPO) connector
- Yes
- Expansion module support
- Yes
Greitas palyginimas
Prekė |
APC Back-UPS Pro BGM2200B-GR - 2200VA/1320W, 4x Schuko & 2x C13 outlets, 3x USB charger, USB dataport | PowerWalker VFI 1500 CG PF1 Double-conversion (Online) 1.5 kVA 1500 W 4 AC outlet(s) | CyberPower OR1500ERM1U uninterruptible power supply (UPS) Line-Interactive 1500 VA 900 W 6 AC outlet(s) | APC Smart-UPS SMT750IC - 6x C13, USB, SmartConnect, 750VA |
Prieinamumas |
|
|
|
|
Kaina |
491,72 €
|
493,45 €
|
499,71 €
|
510,92 €
|
Aprašymas |
||||
Package type |
Box | |||
Cable length |
1.52 m | 1.83 m | 1.83 m | |
Width |
104.1 mm | 145 mm | 443 mm | 138 mm |
Height |
292.1 mm | 221 mm | 44 mm | 157 mm |
Depth |
408.9 mm | 397 mm | 389 mm | 358 mm |
Weight |
12.3 kg | 14.6 kg | 14.9 kg | 13.2 kg |
Package depth |
480 mm | |||
Package height |
155 mm | 325 mm | 301 mm | |
Package width |
355 mm | 230 mm | 278 mm | |
Package weight |
14.5 kg | |||
Number of batteries supported |
1 | 3 | ||
Cables included |
USB cable | Input power cable, Output power cable, USB cable | USB cable | |
Storage relative humidity (H-H) |
0 - 95% | 0 - 95% | 0 - 95% | |
Manual |
Yes | Yes | Yes | |
Operating temperature (T-T) |
0 - 40 °C | 0 - 40 °C | 0 - 40 °C | 0 - 40 °C |
Operating relative humidity (H-H) |
0 - 95% | 20 - 95% | 0 - 95% | 5 - 95% |
Storage temperature (T-T) |
-15 - 40 °C | -15 - 45 °C | -15 - 45 °C | |
Form factor |
Tower | Tower | Rackmount | Tower |
USB port |
Yes | Yes | Yes | Yes |
LED indicators |
Status | |||
Battery technology |
Sealed Lead Acid (VRLA) | Sealed Lead Acid (VRLA) | Sealed Lead Acid (VRLA) | |
Battery life (max) |
5 year(s) | 5 year(s) | ||
Battery capacity |
9 Ah | |||
Battery recharge time |
16 h | 3 h | 3 h | |
Cooling type |
Active | |||
Display |
LCD | |||
Output power |
1320 W | 1500 W | 900 W | 500 W |
Input frequency |
50/60 Hz | 40/70 Hz | 50/60 Hz | 50/60 Hz |
Response time |
8 ms | |||
Display type |
LCD | LCD | LCD | |
Ethernet LAN (RJ-45) ports |
1 | |||
Efficiency |
89% | 98% | ||
Input operation voltage (min) |
168 V | 110 V | 165 V | 151 V |
Power protection features |
Overload | |||
Cold start |
Yes | Yes | ||
AC outlets quantity |
6 AC outlet(s) | 4 AC outlet(s) | 6 AC outlet(s) | 6 AC outlet(s) |
Output power capacity |
2.2 kVA | 1.5 kVA | 1500 kVA | 0.75 kVA |
Output operation voltage (max) |
230 V | 240 V | 230 V | 240 V |
Waveform |
Sine | Sine | Sine | |
Auto-restart |
Yes | |||
AC outlet types |
Type F | C13 coupler | C13 coupler | C13 coupler |
Input operation voltage (max) |
302 V | 300 V | 271 V | 302 V |
Audible alarm(s) |
Yes | Yes | Yes | |
Battery voltage |
24 V | 12 V | ||
Output operation voltage (min) |
200 V | 220 V | ||
UPS topology |
Line-Interactive | Double-conversion (Online) | Line-Interactive | Line-Interactive |
Typical backup time at full load |
3 min | 4.6 min | ||
Warranty card |
Yes | |||
Cabling technology |
10/100/1000Base-T(X) | |||
Automatic Voltage Regulation (AVR) |
Yes | Yes | Yes | |
Automatic battery test |
Yes | Yes | ||
Typical backup time at half load |
10.3 min | 15.8 min | ||
Surge protection |
Yes | Yes | ||
Output voltage regulation |
1% | |||
Operating altitude |
0 - 3048 m | 0 - 3000 m | ||
International Protection (IP) code |
IP20 | |||
Serial interface type |
RJ-45 | RS-232 | ||
Quick installation guide |
Yes | |||
Output frequency |
60 Hz | 50/60 Hz | ||
Noise Level |
45 dB | 50 dB | 40 dB | |
Maximum current |
12 A | |||
Surge energy rating |
1080 J | 540 J | ||
Power plug |
Type F | C14 coupler | C14 coupler | |
Non-operating altitude |
0 - 3048 m | 0 - 15000 m | ||
Product colour |
Black | Black | Silver | Black |
Harmonized System (HS) code |
85078000 | |||
Sustainability certificates |
Green Premium | RoHS | Green Premium | |
Serial interface |
Yes | |||
Output voltage Total Harmonic Distortion (THD) |
2% | |||
Hot-swap battery |
Yes | Yes | ||
Compliance certificates |
RoHS | |||
Audible alarm modes |
Alarm when on battery, Low battery alarm, Overload alarm | Fault, Low battery alarm, Overload alarm | ||
Power factor |
0.99 | |||
Surge protection features |
Network | Modem | ||
Number of output IEC jumpers |
2 | |||
SmartSlot |
Yes | |||
Crest factor |
3:1 | |||
Emergency Power Off (EPO) |
Yes | |||
Rack capacity |
0U | 1U | ||
Resource CD |
Yes | |||
EMI/RFI noise filtering |
Yes | Yes | ||
Emergency Power Off (EPO) connector |
Yes | |||
Input current Total Harmonic Distortion (THD) |
1.6% | |||
