Prekė detaliau
Charakteristikos
- Width
- 84 mm
- Height
- 158 mm
- Depth
- 252 mm
- Weight
- 3.8 kg
- Number of batteries supported
- 1
- Storage relative humidity (H-H)
- 20 - 95%
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 20 - 80%
- Storage temperature (T-T)
- 0 - 40 °C
- Form factor
- Tower
- USB port
- Yes
- Battery technology
- Sealed Lead Acid (VRLA)
- Battery capacity
- 5 Ah
- Cooling type
- Natural
- Output power
- 330 W
- Input frequency
- 50/60 Hz
- Input operation voltage (min)
- 162 V
- Power protection features
- Overload
- Cold start
- Yes
- AC outlets quantity
- 3 AC outlet(s)
- Output power capacity
- 0.55 kVA
- Output operation voltage (max)
- 253 V
- Waveform
- Sine
- AC outlet types
- Type E (FR)
- Input operation voltage (max)
- 290 V
- Audible alarm(s)
- Yes
- Battery voltage
- 12 V
- Output operation voltage (min)
- 191 V
- UPS topology
- Line-Interactive
- Automatic Voltage Regulation (AVR)
- Yes
- Surge protection
- Yes
- International Protection (IP) code
- IP20
- Output frequency
- 50/60 Hz
- Product colour
- Black
- Audible alarm modes
- Fault, Low battery alarm, Overload alarm
- Number of input phases
- 1
- Number of output phases
- 1
Greitas palyginimas
Prekė |
![]() |
|
![]() |
![]() |
Prieinamumas |
|
|
|
|
Kaina |
69,97 €
|
70,40 €
|
71,38 €
|
72,27 €
|
Aprašymas |
Eaton UPS 5E Gen2 700D DIN 700 VA, 360 W, Tower, Line-Interactive | Eaton 5E Gen2 UPS USB IEC, 700 VA, 360 W, Input: C14, Outputs: (4) C13, Tower | ||
Colour of product |
Black | |||
Warranty |
24 month(s) | 24 month(s) | ||
Producer product name |
5E Gen2 700D DIN | |||
Net weight |
4.30 kg | 4.18 kg | ||
Gross weight |
4.84 kg | 4.72 kg | ||
WEEE tax |
Yes | Yes | ||
Packing quantity |
1.00 pc(s) | 1 pc(s) | ||
Volume (m3) |
0.01 m | 0.004437 m | ||
Tare weight (kg) |
0.54 kg | 0.54 kg | ||
Gross depth (mm) |
305.00 mm | 290 mm | ||
Gross width (mm) |
198.00 mm | 102 mm | ||
Gross height (mm) |
105.00 mm | 150 mm | ||
WEE classification |
CL109:5:2017-04-01 | CL109:5:2017-04-01 | ||
Paper/Pasteboard |
500.00 g | 340 g | ||
Embeeded battery |
Yes | Yes | ||
TI weight (kg) |
1.30 kg | |||
Width |
100 mm | 270 mm | ||
Height |
148 mm | 90 mm | ||
Depth |
288 mm | 190 mm | ||
Plastic (No PET) |
40.00 g | 200 g | ||
Composition of battery |
CL127:KT:2016-12-09 | CL127:KT:2016-12-09 | ||
Classification of battery |
CL126:NE:2016-12-09 | CL126:NE:2016-12-09 | ||
Type of battery |
Accumulator | Accumulator | ||
Weight |
3.8 kg | 3.55 kg | ||
Producer product family |
UPS | |||
Power source type |
AC | |||
Operating temperature (T-T) |
0 - 40 °C | |||
Form factor |
Tower | Tower | ||
USB port |
Yes | |||
Battery capacity |
7 Ah | |||
Capacity |
360 W | |||
Control type |
Buttons | |||
Palette Qty |
207 pc(s) | 195 pc(s) | ||
Battery recharge time |
8 h | |||
Display |
LCD | |||
Output power |
300 W | 360 W | ||
Input frequency |
50/60 Hz | 50/60 Hz | ||
USB 2.0 ports quantity |
2 | |||
Response time |
2 ms | |||
Ethernet LAN (RJ-45) ports |
2 | |||
Input operation voltage (min) |
220 V | 220 V | ||
Power protection features |
Over voltage | Short circuit | ||
Cold start |
Yes | |||
AC outlets quantity |
4 AC outlet(s) | 6 AC outlet(s) | ||
Output power capacity |
0.55 kVA | 600 VA | ||
Output operation voltage (max) |
240 V | 230 V | ||
Waveform |
Approximate sine wave | |||
Auto-restart |
Yes | |||
AC outlet types |
C13 coupler | |||
Input operation voltage (max) |
240 V | 240 V | ||
Audible alarm(s) |
Yes | |||
Battery voltage |
12 V | |||
Output operation voltage (min) |
220 V | 230 V | ||
UPS topology |
Line-Interactive | Line-Interactive | Line-Interactive | |
Automatic battery test |
Yes | |||
Output frequency |
50/60 Hz | |||
Noise Level |
25 dB | |||
Product colour |
Black | Black | ||
Sustainability certificates |
Low Voltage Directive (LVD) | |||
Sustainability compliance |
Yes | |||
Producer |
Eaton | |||
Audible alarm modes |
Battery replacement | |||
