Prekė detaliau
Charakteristikos
- Width
- 170 mm
- Height
- 216 mm
- Depth
- 440 mm
- Weight
- 27.5 kg
- Package depth
- 590 mm
- Package height
- 330 mm
- Package width
- 370 mm
- Package weight
- 30 kg
- Number of batteries supported
- 1
- Cables included
- USB cable
- Storage relative humidity (H-H)
- 0 - 95%
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Storage temperature (T-T)
- -15 - 45 °C
- Form factor
- Compact
- USB port
- Yes
- LED indicators
- Yes
- Battery technology
- Sealed Lead Acid (VRLA)
- Battery life (max)
- 5 year(s)
- Battery capacity
- 499 VAh
- Battery recharge time
- 3 h
- Output power
- 1300 W
- Input frequency
- 47/63 Hz
- Display type
- LCD
- Input operation voltage (min)
- 170 V
- Cold start
- Yes
- AC outlets quantity
- 7 AC outlet(s)
- Output power capacity
- 2 kVA
- Output operation voltage (max)
- 230 V
- Waveform
- Sine
- Auto-restart
- Yes
- AC outlet types
- C20 coupler
- Input operation voltage (max)
- 300 V
- Audible alarm(s)
- Yes
- UPS topology
- Line-Interactive
- Automatic Voltage Regulation (AVR)
- Yes
- Automatic battery test
- Yes
- Surge protection
- Yes
- Operating altitude
- 0 - 3000 m
- Web-based management
- Yes
- Noise Level
- 45 dB
- Surge energy rating
- 300 J
- Non-operating altitude
- 0 - 15000 m
- Product colour
- Black
- Software CD
- Yes
- Output voltage Total Harmonic Distortion (THD)
- 5%
- Hot-swap battery
- Yes
- Compliance certificates
- RoHS
- Total carbon footprint (kg of CO2e)
- 2269.61
- Audible alarm modes
- Low battery alarm
- Resource CD
- Yes
