![Switch|DAHUA|Type L2|Desktop/pedestal|90 Watts|PFS4218-16ET-240-V3 Switch|DAHUA|Type L2|Desktop/pedestal|90 Watts|PFS4218-16ET-240-V3](https://ecomp.lt/2940265-large_default/switchdahuatype-l2desktop-pedestal90-wattspfs4218-16et-240-v3.jpg)
> Layer 2 management PoE switch
> Intelligent PoE
> Red port supports 90W IEEE802.3bt
> Web management with friendly interface and easy operation
> 250 m long distance PoE transmission
> PoE watchdog
> Plug and play
Communication Standard: IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE 802.3ab; IEEE 802.3z
PoE Standard: IEEE802.3af/ IEEE802.3at/ Hi-PoE/IEEE802.3bt
Port 1-16: 16 × RJ-45 10 M/100 M (PoE)
Port 17-18: 2 × RJ-45 10 M/100 M/1000 M (uplink)
Port 17-18: 2 × SFP 1000 M (uplink) (combo)
PoE Budget: Port 1-2 ≤ 90W, Port 3-16≤ 30W, total ≤ 240W
> Intelligent PoE
> Red port supports 90W IEEE802.3bt
> Web management with friendly interface and easy operation
> 250 m long distance PoE transmission
> PoE watchdog
> Plug and play
Communication Standard: IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE 802.3ab; IEEE 802.3z
PoE Standard: IEEE802.3af/ IEEE802.3at/ Hi-PoE/IEEE802.3bt
Port 1-16: 16 × RJ-45 10 M/100 M (PoE)
Port 17-18: 2 × RJ-45 10 M/100 M/1000 M (uplink)
Port 17-18: 2 × SFP 1000 M (uplink) (combo)
PoE Budget: Port 1-2 ≤ 90W, Port 3-16≤ 30W, total ≤ 240W
Prekė detaliau
Charakteristikos
- Switch type
- L2
- Garantija
- 36
- Category Code
- SWI
- Unit Box Height
- 0.415
- Unit Box Length
- 0.53
- Unit Box Width
- 0.11
- Unit Net Weight
- 3.32 kg
- Vendor Homepage
- www.dahuasecurity.com/products/All-Products/Transmission/PoE-Switches/Desktop-PoE-Switch/PFS4218-16ET-240
- Dimensions
- 440 mm 300 mm 44 mm
- Mounting Type (Desktop/pedestal)
- Yes
- LAN Ports (10/100/1000M)
- 2
- LAN Ports (10/100M)
- 16
- LAN Ports (Combo 10/100/1000M-T/SFP)
- 2
- Network standard (IEEE 802.3)
- Yes
- Network standard (IEEE 802.3ab)
- Yes
- Network standard (IEEE 802.3u)
- Yes
- Network standard (IEEE 802.3x)
- Yes
- Network standard (IEEE 802.3z)
- Yes
- Switching capacity
- 8.8 Gbps
- Primary port count
- 16
- Forwarding rate
- 5.36 Mpps
- PoE power budget
- 90 Watts
