Prekė detaliau
Charakteristikos
- Type
- IP security camera
- Height
- 332 mm
- Connectivity technology
- Wired
- Weight
- 4.7 kg
- Package weight
- 8 kg
- Power source type
- DC, PoE
- Operating temperature (T-T)
- -40 - 70 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Mounting type
- Ceiling
- Form factor
- Dome
- Bluetooth
- No
- Noise reduction
- Yes
- Sensor type
- CMOS
- Wi-Fi
- No
- Internal memory
- 1000 MB
- Compatible memory cards
- MicroSD (TransFlash)
- Maximum memory card size
- 512 GB
- Display diagonal
- 2.54 cm (1")
- Audio formats supported
- G.726
- Power consumption (max)
- 22 W
- Power consumption (typical)
- 13 W
- Maximum resolution
- 2560 x 1440 pixels
- Placement supported
- Indoor & outdoor
- Ethernet LAN (RJ-45) ports
- 1
- Ethernet LAN
- Yes
- Headphone outputs
- 1
- Focus
- Manual
- Supported graphics resolutions
- 2560 x 1440
- Zoom capability
- Yes
- Diameter
- 19 cm
- International Protection (IP) code
- IP67
- Digital zoom
- 16x
- Auto focus
- Yes
- Optical Zoom
- 32x
- Web-based management
- Yes
- Product colour
- White
- Tilt angle range
- 15 - 90°
- Focal length range
- 4.8–154
- Web browser
- Yes
- LED type
- IR
- Night vision
- Yes
- Total megapixels
- 4 MP
- PTZ control
- Yes
- Optical sensor size
- 25.4 / 2.8 mm (1 / 2.8")
- White balance
- Manual
- Minimum illumination
- 0.0005 lx
- Pan range
- 0 - 360°
- Lens viewing angle, diagonal
- 67.5–3.2
- Video compression formats
- H.264B
- DC output current
- 2.5 A
- DC output voltage
- 24
- Number of cameras
- 1
- Camera pan control
- Yes
- Camera tilt control
- Yes
- Night vision distance
- 150 m
- Number of lenses
- 1
- Auto-tracking
- Yes
- Built-in HDD
- No
- Lens viewing angle, vertical
- 31.9–1.3
- Noise reduction technology
- 2D noise reduction, 3D noise reduction
- Digital Wide Dynamic Range (DWDR)
- Yes
- Maximum aperture number
- 4
- Lens viewing angle, horizontal
- 58.5–2.8
- Wide Dynamic Range (WDR)
- Yes
- Progressive scan
- Yes
- Back Light Compensation (BLC)
- Yes
- ROM capacity
- 4000 MB
- Number of illumination LEDs
- 4
- IK code
- IK10
- Digital Wide Dynamic Range (DWDR) (panoramic camera)
- Yes
- Closest focusing distance
- 0.8 m
- Detect distance
- 2124 m
- Observe distance
- 839 m
- Recognize distance
- 425 m
- Identify distance
- 212 m
- Minimum aperture number
- 1.6
- Pan preset speed
- 400 °/sec
- PTZ modes
- 5 Pattern
- Tilt preset speed
- 300 °/sec
- Pan manual speed
- 0.1 - 300 °/sec
- Tilt manual speed
- 0.1 - 200 °/sec
- Warnings
- Avoid direct contact with water to prevent electrical damage.
Greitas palyginimas
Prekė |
Axis M3216-LVE Dome IP security camera Indoor & outdoor 2688 x 1512 pixels Ceiling/wall
|
FishEye 360 4K IP kam.12MP(4000x3000) STARLIGHT STARVIS sensor. 25fps, H.265, IR, IP67, IK10, PoE
|
|
Prieinamumas |
|
|
|
Kaina |
843,73 €
|
847,85 €
|
849,90 €
|
Aprašymas |
|||
Type |
IP security camera | IP security camera | |
Height |
102 mm | 332 mm | |
Connectivity technology |
Wired | Wired | |
Weight |
791 g | 4.7 kg | |
Package weight |
8 kg | ||
Power source type |
PoE | DC, PoE | |
Storage relative humidity (H-H) |
5 - 95% | ||
Operating temperature (T-T) |
-40 - 50 °C | -40 - 70 °C | |
Operating relative humidity (H-H) |
10 - 100% | 0 - 95% | |
Storage temperature (T-T) |
-40 - 65 °C | ||
Mounting type |
Ceiling/wall | Ceiling/wall | |
Form factor |
Dome | Dome | |
Bluetooth |
No | ||
Bit rate |
H.264: 96 kbps–14848 kbps; H.265: 38 kbps–8960 kbps | ||
Noise reduction |
Yes | ||
Mobile operating systems supported |
iOS | ||
Microphone in |
Yes | ||
Sensor type |
CMOS | CMOS | |
Wi-Fi |
No | ||
Internal memory |
1024 MB | 1000 MB | |
Compatible memory cards |
MicroSD (TransFlash) | MicroSD (TransFlash) | |
Maximum memory card size |
512 GB | ||
Signal-to-Noise Ratio (SNR) |
55 dB | ||
Power consumption (max) |
22 W | ||
Power consumption (typical) |
10 W | ||
Maximum resolution |
2688 x 1512 pixels | 2560 x 1440 pixels | |
Placement supported |
Indoor & outdoor | Outdoor | |
Card reader integrated |
Yes | ||
Ethernet LAN (RJ-45) ports |
1 | 1 | |
Audio output channels |
1.0 channels | ||
Housing material |
Polycarbonate (PC) | ||
Networking standards |
IEEE 802.1x | IEEE 802.3at | |
Security algorithms |
HTTPS | ||
Ethernet LAN |
Yes | Yes | |
Supported graphics resolutions |
1920 x 1080 (HD 1080) | ||
Zoom capability |
Yes | Yes | |
Diameter |
14.9 cm | 19 cm | |
International Protection (IP) code |
IP66 | IP67 | |
Flash memory |
8192 MB | ||
Digital zoom |
16x | ||
Ethernet interface type |
Fast Ethernet | ||
Optical Zoom |
45x | ||
Number of Users |
20 user(s) | ||
Web-based management |
Yes | ||
Quality of Service (QoS) support |
Yes | ||
Frame Rate |
30 fps | ||
Product colour |
White | White | |
Tilt angle range |
-10 - 80° | -15 - 90° | |
Focal length range |
3.95 - 177.75 mm | ||
Fixed focal length |
2.9 mm | ||
Voice codecs |
G.723 | ||
Image stabilizer |
Yes | ||
LED type |
IR | IR | |
Night vision |
Yes | Yes | |
Total megapixels |
4 MP | ||
PTZ control |
Yes | Yes | |
Optical sensor size |
25.4 / 2.7 mm (1 / 2.7") | 25.4 / 2.8 mm (1 / 2.8") | |
White balance |
Manual | ||
Minimum illumination |
0.16 lx | 0.0005 lx | |
Pan range |
0 - 190° | 0 - 360° | |
Lens viewing angle, diagonal |
2.1 - 73.1° | ||
Video compression formats |
H.264 | H.265 | |
Angle of rotation |
190° | 360° | |
DC output voltage |
24 | ||
Video motion detection |
Yes | ||
Number of cameras |
1 | 1 | |
Night vision distance |
150 m | ||
Number of lenses |
1 | ||
Day/night mode |
Yes | Yes | |
Preset points |
Yes | ||
Auto-tracking |
Yes | ||
Built-in HDD |
No | No | |
Camera shutter type |
Electronic | ||
Lens viewing angle, vertical |
73° | 1.1 - 39.4° | |
Noise reduction technology |
2D noise reduction, 3D noise reduction | ||
Smart IR |
Yes | ||
Region of Interest (ROI) encoding |
Yes | ||
Maximum aperture number |
4.95 | ||
Lens viewing angle, horizontal |
102° | 1.9 - 65.7° | |
Wide Dynamic Range (WDR) |
Yes | Yes | |
Progressive scan |
Yes | Yes | |
Back Light Compensation (BLC) |
Yes | ||
Video streaming |
Yes | Yes | |
Fog proof |
Yes | Yes | |
Active tampering alarm |
Yes | ||
Alarm input/output |
Yes | ||
Auto flip |
Yes | ||
Intelligent Video Surveillance (IVS) system features |
Missing object | ||
ROM capacity |
4000 MB | ||
Camera shutter speed |
1/50000 - 1/5 s | 1/1 - 1/30000 s | |
Bit rate control |
Constant Bit Rate (CBR), Variable Bit Rate (VBR) | ||
Gain control type |
Auto/Manual | ||
Privacy masking |
Yes | Yes | |
Highlight Compensation (HLC) |
Yes | ||
Number of illumination LEDs |
4 | ||
Power consumption (Power over Ethernet (PoE)) |
4.8 W | ||
HTTPS encryption |
Yes | ||
IK code |
IK10 | IK10 | |
Streaming method |
Multicast | ||
Audio input channels |
1.0 channels | ||
Closest focusing distance |
1 m | 0.1 m | |
Detect distance |
2451.7 m | ||
Observe distance |
972.9 m | ||
Recognize distance |
490.3 m | ||
Identify distance |
245.2 m | ||
Minimum aperture number |
2 | ||
Pan preset speed |
400 °/sec | ||
PTZ modes |
Digital PTZ | ||
Tilt preset speed |
300 °/sec | ||
PTZ protocols |
DH-SD | ||
Alarm output channels |
1 | ||
Alarm input channels |
2 | ||
Pan manual speed |
0.1 - 300 °/sec | ||
Tilt manual speed |
0.1 - 120 °/sec | ||
Warnings |
Avoid direct contact with water to prevent electrical damage. | ||
Tour recording |
Yes | ||
