Charakteristikos
- Type
- IP security camera
- Height
- 93.4 mm
- Connectivity technology
- Wired
- Weight
- 520 g
- Package weight
- 680 g
- Power source type
- DC, PoE
- Operating temperature (T-T)
- -30 - 60 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Storage temperature (T-T)
- -40 - 60 °C
- Mounting type
- Ceiling
- Form factor
- Dome
- Built-in microphone
- Yes
- Bluetooth
- No
- Bit rate
- 12 kbps–6144 kbps
- Noise reduction
- Yes
- Mobile operating systems supported
- Android
- Sensor type
- CMOS
- Wi-Fi
- No
- Internal memory
- 128 MB
- Compatible memory cards
- MicroSD (TransFlash)
- Maximum memory card size
- 256 GB
- Audio formats supported
- G.726
- Signal-to-Noise Ratio (SNR)
- 56 dB
- Power consumption (max)
- 6.5 W
- Power consumption (typical)
- 2.3 W
- Maximum resolution
- 2688 x 1520 pixels
- Built-in speaker(s)
- Yes
- Placement supported
- Outdoor
- Card reader integrated
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- Audio output channels
- 1.0 channels
- Housing material
- Metal
- Ethernet LAN
- Yes
- Supported graphics resolutions
- 2560 x 1440
- Diameter
- 12.2 cm
- International Protection (IP) code
- IP67
- Flash memory
- 128 MB
- Number of Users
- 6 user(s)
- Supported network protocols
- IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP
- Product colour
- White
- Tilt angle range
- 0 - 75°
- Focal length range
- 2.7 - 13.5 mm
- Web browser
- No
- LED type
- IR
- Night vision
- Yes
- Total megapixels
- 4 MP
- Optical sensor size
- 25.4 / 2.9 mm (1 / 2.9")
- White balance
- Outdoor
- Minimum illumination
- 0 lx
- Pan range
- 0 - 355°
- Dynamic range
- 120 dB
- Lens viewing angle, diagonal
- 125 - 34°
- Video compression formats
- H.265
- Angle of rotation
- 355°
- DC output voltage
- 12
- Video motion detection
- Yes
- Number of cameras
- 1
- Night vision distance
- 40 m
- Day/night mode
- Yes
- Built-in HDD
- No
- Camera shutter type
- Electronic
- Lens viewing angle, vertical
- 54 - 16°
- Noise reduction technology
- 3D noise reduction
- Lens viewing angle, horizontal
- 104 - 29°
- Wide Dynamic Range (WDR)
- Yes
- Progressive scan
- Yes
- Mirror
- Yes
- Back Light Compensation (BLC)
- Yes
- Camera shutter speed
- 1/3 - 1/100000 s
- Adjustment shutter speed
- Auto/Manual
- Bit rate control
- Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Gain control type
- Auto/Manual
- Highlight Compensation (HLC)
- Yes
- Number of illumination LEDs
- 2
- Power consumption (Power over Ethernet (PoE))
- 3.2 W
- IK code
- IK10
- Identify distance (wide)
- 6.4 m
- Recognize distance (wide)
- 12.8 m
- Audio input channels
- 1.0 channels
- Observe distance (wide)
- 25.6 m
- Management software
- Smart PSS; DSS; DMSS
- Closest focusing distance
- 0.8 m
- Detect distance (wide)
- 64 m
- Identify distance (tele)
- 21 m
- Minimum aperture number
- 1.5
- Recognize distance (tele)
- 42 m
- Detect distance (tele)
- 210 m
- Observe distance (tele)
- 84 m
- Alarm output channels
- 1
- Alarm input channels
- 1
- Number of Privacy masking areas
- 4
- Warnings
- The product contains electronic components; do not dispose of with the normal household waste.
Greitas palyginimas
Prekė |
Hikvision Bullet IR DS-2CD2046G2-IU/SL(2.8mm)(C) 4MP
|
DS-2CD2146G2H-ISU(2.8mm)(BLACK) Camera
|
IP kamera HDW2841E-S, 8MP, IR pašvietimas iki 30m, 2.8mm 106 , SMD, IVS
|
HIKVISION IP CAMERA DS-2CD2T46G2H-2I(2.8mm)(eF)
|
Prieinamumas |
|
|
|
|
Kaina |
162,01 €
|
162,26 €
|
162,65 €
|
163,08 €
|
Aprašymas |
||||
Type |
IP security camera | IP security camera | ||
Width |
72.9 mm | |||
Height |
97.6 mm | |||
Depth |
73.3 mm | |||
Connectivity technology |
Wired | Wired | ||
Weight |
590 g | 550 g | ||
Package depth |
120 mm | 150 mm | ||
Package height |
117 mm | 141 mm | ||
Package width |
234 mm | 150 mm | ||
Package weight |
820 g | 800 g | ||
Power source type |
DC, PoE | DC, PoE | ||
Storage relative humidity (H-H) |
0 - 95% | 0 - 95% | ||
Operating temperature (T-T) |
-30 - 60 °C | -30 - 60 °C | ||
Operating relative humidity (H-H) |
0 - 95% | 0 - 95% | ||
Storage temperature (T-T) |
-30 - 60 °C | -30 - 60 °C | ||
Mounting type |
Ceiling/wall | Ceiling/wall | ||
Form factor |
Bullet | Bullet | ||
Built-in microphone |
Yes | Yes | ||
Bluetooth |
No | No | ||
Sample rate |
48 kHz | |||
Bit rate |
32 Kbps - 8 Mbps | 32 Kbps - 8192 Kbps | ||
Noise reduction |
Yes | Yes | ||
Protection features |
Dust resistant | |||
Sensor type |
CMOS | CMOS | ||
Wi-Fi |
No | No | ||
Compatible memory cards |
microSDHC | MicroSD (TransFlash) | ||
Maximum memory card size |
256 GB | 512 GB | ||
Audio formats supported |
MP3 | G.722.1 | ||
Signal-to-Noise Ratio (SNR) |
52 dB | |||
Power consumption (max) |
6.5 W | 7.2 W | ||
Maximum resolution |
2688 x 1520 pixels | 2688 x 1520 pixels | ||
Built-in speaker(s) |
Yes | |||
Placement supported |
Outdoor | Outdoor | ||
Card reader integrated |
Yes | Yes | ||
Ethernet LAN (RJ-45) ports |
1 | 1 | ||
Number of languages |
33 | 33 | ||
Audio output channels |
1.0 channels | |||
Housing material |
Aluminium | Aluminium | ||
Networking standards |
IEEE 802.1x | IEEE 802.3af | ||
Security algorithms |
HTTPS | |||
Ethernet LAN |
Yes | Yes | ||
Supported graphics resolutions |
2688 x 1520 | 2688 x 1520 | ||
Diameter |
12.2 cm | |||
International Protection (IP) code |
IP67 | IP67 | ||
Ethernet interface type |
Fast Ethernet | Fast Ethernet | ||
Number of Users |
32 user(s) | 32 user(s) | ||
Web-based management |
Yes | Yes | ||
Quality of Service (QoS) support |
Yes | Yes | ||
Reset button |
Yes | Yes | ||
Browser supported |
IE 10, IE 11, Chrome 57.0+, Firefox 52.0+ | |||
Password protection |
Yes | Yes | ||
Languages support |
Korean | Multi | ||
Frame Rate |
30 fps | 30 fps | ||
Product colour |
White | Black | ||
Tilt angle range |
0 - 90° | 0 - 75° | ||
Sustainability certificates |
REACH | |||
Fixed focal length |
2.8 mm | |||
Voice codecs |
AAC | |||
LED type |
IR | IR | ||
Night vision |
Yes | Yes | ||
Total megapixels |
4 MP | 4 MP | ||
Optical sensor size |
25.4 / 3 mm (1 / 3") | 25.4 / 3 mm (1 / 3") | ||
Minimum illumination |
0 lx | |||
Pan range |
0 - 360° | 0 - 355° | ||
Dynamic range |
130 dB | |||
Lens viewing angle, diagonal |
123° | 119.7° | ||
Video compression formats |
H.265+ | H.265+ | ||
Angle of rotation |
360° | 355° | ||
DC output current |
0.6 A | |||
DC output voltage |
12 | 12 | ||
Video motion detection |
Yes | Yes | ||
Number of cameras |
1 | 1 | ||
Camera pan control |
Yes | |||
Camera tilt control |
Yes | |||
Night vision distance |
40 m | 30 m | ||
Number of lenses |
1 | 1 | ||
Privacy protection |
Yes | |||
Day/night mode |
Yes | Yes | ||
Infrared (IR) cut-off filter |
Yes | Yes | ||
Built-in HDD |
No | No | ||
Lens viewing angle, vertical |
55° | 54.7° | ||
Noise reduction technology |
3D noise reduction | 3D noise reduction | ||
Region of Interest (ROI) encoding |
Yes | Yes | ||
Maximum aperture number |
1.4 | 1 | ||
Lens viewing angle, horizontal |
103° | 100.2° | ||
Number of sensors |
1 | 1 | ||
Infra-red wavelength |
850 nm | 850 nm | ||
Wide Dynamic Range (WDR) |
Yes | Yes | ||
Progressive scan |
Yes | Yes | ||
Mirror |
Yes | Yes | ||
Heartbeat |
Yes | Yes | ||
Anti-flicker |
Yes | |||
Back Light Compensation (BLC) |
Yes | Yes | ||
Video streaming |
Yes | Yes | ||
Active tampering alarm |
Yes | |||
Alarm input/output |
Yes | |||
Terminal block port |
Yes | |||
IP address filtering |
Yes | Yes | ||
Intelligent Video Surveillance (IVS) system features |
Scene change | Face detection | ||
Camera shutter speed |
1/3 - 1/100000 s | 1/3 - 1/100000 s | ||
Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) | ||
Privacy masking |
Yes | Yes | ||
Highlight Compensation (HLC) |
Yes | Yes | ||
Live view |
Yes | |||
Power consumption (Power over Ethernet (PoE)) |
8 W | 8.5 W | ||
HTTPS encryption |
Yes | Yes | ||
Behavior analysis |
Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection | Intrusion detection, Line crossing detection | ||
Image quality adjustment |
Brightness | Saturation | ||
IK code |
IK10 | |||
Lens mount interface |
M12 | |||
Digest authentication |
Yes | |||
Password reset via email |
Yes | |||
Number of simultaneous live view channels |
6 channels | |||
User access level |
Administrator, Operator, User | |||
Identify distance (wide) |
6 m | |||
Recognize distance (wide) |
12 m | |||
Audio input channels |
1.0 channels | |||
Detect distance |
63 m | |||
Observe distance |
25 m | |||
Recognize distance |
12 m | |||
Identify distance |
6 m | |||
Pixel counter |
Yes | |||
Human and vehicle targets classification |
Yes | |||
Client interoperability |
iVMS-4200, Hik-Connect, Hik-Central | |||
Bit rate range |
8 - 320 Kbit/s | |||
Alarm output channels |
1 | |||
Alarm input channels |
1 | |||
Compliance certificates |
RoHS | |||
Number of Privacy masking areas |
4 | |||
Sample rates |
8 - 48 kHz | |||
Automatic Network Replenishment (ANR) |
Yes | |||
Network access storage (NAS) |
Yes | |||
Warnings |
Avoid direct contact with water to prevent electrical damage. | The product contains electronic components; do not dispose of with the normal household waste. | ||
Audit log |
Yes | |||
Flash log |
Yes | |||
