Prekė detaliau
Charakteristikos
- Cable length
- 1.5 m
- Width
- 196 mm
- Height
- 337 mm
- Depth
- 416 mm
- Weight
- 21.3 kg
- Package height
- 458 mm
- Package width
- 295 mm
- Number of batteries supported
- 3
- Cables included
- Power load cable, USB cable
- Storage relative humidity (H-H)
- 10 - 90%
- Operating temperature (T-T)
- 0 - 40 °C
- Operating relative humidity (H-H)
- 20 - 90%
- Storage temperature (T-T)
- -20 - 50 °C
- Form factor
- Tower
- USB port
- Yes
- LED indicators
- Status
- Battery technology
- Sealed Lead Acid (VRLA)
- Battery recharge time
- 4 h
- Output power
- 2700 W
- Input frequency
- 50/60 Hz
- Response time
- 0 ms
- Display type
- LCD
- Input operation voltage (min)
- 190 V
- Power protection features
- Overload
- AC outlets quantity
- 7 AC outlet(s)
- Output power capacity
- 3 kVA
- Output operation voltage (max)
- 240 V
- Waveform
- Pure sine
- AC outlet types
- C13 coupler
- Input operation voltage (max)
- 230 V
- Audible alarm(s)
- Yes
- Output operation voltage (min)
- 208 V
- UPS topology
- Double-conversion (Online)
- Typical backup time at full load
- 4.2 min
- Housing material
- Metal
- Typical backup time at half load
- 13.1 min
- Surge protection
- Yes
- Operating altitude
- 0 - 1500 m
- Output frequency
- 50/60 Hz
- Maximum current
- 13.04 A
- Surge energy rating
- 370 J
- Non-operating altitude
- 0 - 1500 m
- Product colour
- Black
- Harmonized System (HS) code
- 8504408590
- Charging current
- 1.5 A
- Output voltage Total Harmonic Distortion (THD)
- 5%
- Audible alarm modes
- Battery replacement, Fault, Low battery alarm, Overload alarm
- Power factor
- 0.9
- Crest factor
- 3:1
- EMI/RFI noise filtering
- Yes
- Input power factor
- 0.98
- Built-in fan
- Yes
- Efficiency (ECO mode)
- 95%
- Warnings
- Keep away from sources of fire and water.
Greitas palyginimas
Prekė |
UPS|EATON|700 Watts|1000 VA|Wave form type Pure sinewave|LineInteractive|Rack 2U|5SC1000IR
|
|
APC Smart-UPS SMT1000IC – 8x C13, USB, SmartConnect, 1000VA
|
PowerWalker VFI 3000 CRM LCD 3 kVA
|
Prieinamumas |
|
|
|
|
Kaina |
739,05 €
|
742,46 €
|
745,36 €
|
748,88 €
|
Aprašymas |
700 Watts | 1000 VA | Wave form type Pure sinewave | Topology LineInteractive | Input ports Single, IEC320 C14 (10AMP) | Output power connector type IEC 320 C13 | Colour Black | Eaton 9E2000I Online UPS, Tower, 2000 VA / 1600W, Input C14, Output 6xC13 | ||
Warranty |
36 month(s) | |||
Net weight |
22.00 kg | |||
Gross weight |
24.00 kg | |||
WEEE tax |
Yes | |||
Packing quantity |
1.00 pc(s) | |||
Volume (m3) |
0.08 m | |||
Tare weight (kg) |
2.00 kg | |||
Gross depth (mm) |
330.00 mm | |||
Gross width (mm) |
496.00 mm | |||
Gross height (mm) |
464.00 mm | |||
WEE classification |
CL109:6:2017-04-01 | |||
Paper/Pasteboard |
1800.00 g | |||
Embeeded battery |
Yes | |||
Colour |
Black | |||
TI weight (kg) |
16.00 kg | |||
Width |
171 mm | |||
Height |
219 mm | |||
Depth |
439 mm | |||
Plastic (No PET) |
200.00 g | |||
Composition of battery |
CL127:KT:2016-12-09 | |||
Classification of battery |
CL126:NE:2016-12-09 | |||
Type of battery |
Battery | |||
Weight |
18.9 kg | |||
Package height |
376 mm | |||
Package width |
328 mm | |||
Cables included |
RJ-45, USB cable | |||
Storage relative humidity (H-H) |
0 - 95% | |||
Operating temperature (T-T) |
0 - 40 °C | |||
Operating relative humidity (H-H) |
0 - 95% | |||
Storage temperature (T-T) |
-15 - 45 °C | |||
Form factor |
Mini tower | |||
USB port |
Yes | |||
LED indicators |
Yes | |||
Battery technology |
Sealed Lead Acid (VRLA) | |||
Battery life (max) |
5 year(s) | |||
Battery recharge time |
3 h | |||
Output power |
700 W | |||
Input frequency |
50/60 Hz | |||
USB 2.0 ports quantity |
1 | |||
Response time |
10 ms | |||
Display type |
LCD | |||
Ethernet LAN (RJ-45) ports |
1 | |||
Garantija |
24 | |||
Category Code |
UPW | |||
Unit Box Height |
0.235 | |||
Unit Box Length |
0.54 | |||
Unit Box Width |
0.575 | |||
Vendor Homepage |
powerquality.eaton.com/5SC1000iR.aspx?cx 13&GUID E166D4D1-68A2-40B2-A7B6-B8B940ADAA89 | |||
Input operation voltage (min) |
151 V | |||
Cold start |
Yes | |||
AC outlets quantity |
8 AC outlet(s) | |||
Output power capacity |
1 kVA | 3 kVA | ||
Output operation voltage (max) |
240 V | |||
Waveform |
Sine | |||
Auto-restart |
Yes | |||
AC outlet types |
C13 coupler | C13 coupler | ||
Input operation voltage (max) |
302 V | |||
Audible alarm(s) |
Yes | |||
Output operation voltage (min) |
220 V | |||
UPS topology |
Line-Interactive | |||
Automatic Voltage Regulation (AVR) |
Yes | |||
Automatic battery test |
Yes | |||
Surge protection |
Yes | |||
Operating altitude |
0 - 3000 m | |||
Quick installation guide |
Yes | |||
Output frequency |
50/60 Hz | |||
Mounting Type (Rack 2U) |
Yes | |||
Noise Level |
41 dB | |||
Serial ports quantity |
1 | |||
Surge energy rating |
459 J | |||
Power plug |
C14 coupler | |||
Non-operating altitude |
0 - 15000 m | |||
Product colour |
Black | |||
Harmonized System (HS) code |
85078000 | 85078000 | ||
Sustainability certificates |
Green Premium | |||
Serial interface |
Yes | |||
USB port type |
USB Type-A | |||
Output voltage Total Harmonic Distortion (THD) |
5% | |||
Hot-swap battery |
Yes | |||
Compliance certificates |
RoHS | |||
Total carbon footprint (kg of CO2e) |
984.74 | |||
Audible alarm modes |
Alarm when on battery, Low battery alarm, Overload alarm | |||
Temperature voltage compensation |
Yes | |||
SmartSlot |
Yes | |||
Replacement battery cartridge |
RBC6 | |||
Management card included |
No | |||
Warnings |
Do not disassemble the unit housing, there may be a risk of electric shock. | Use the appliance in well-ventilated areas to avoid overheating. | ||
Units per Shipping Box |
1 | |||
Product Net Weight |
14.96 kg | |||
Unit Calculated Weight |
19 kg | |||
Unit Calculated Volume |
0.07297 cubm | |||
Output power capacity, W |
700 Watts | |||
Output power capacity, VA |
1000 VA | |||
Wave form type |
Pure sinewave | |||
Topology |
LineInteractive | |||
Input ports |
Single, IEC320 C14 (10AMP) | |||
Output power connector type |
IEC 320 C13 | |||
Communication ports (USB) |
1 | |||
Communication ports (RS232) |
1 | |||
SmartConnect port |
Yes | |||
