UPS|EATON|1500 Watts|1500 VA|Wave form type Pure sinewave|LineInteractive|Phase 1phase|Desktop/pedestal|Rack 2U|5PX1500IRT2UG2
    EATON

    UPS|EATON|1500 Watts|1500 VA|Wave form type Pure sinewave|LineInteractive|Phase 1phase|Desktop/pedestal|Rack 2U|5PX1500IRT2UG2

    1 205,05 €
    Su mokesčiais
    1500 Watts | 1500 VA | Wave form type Pure sinewave | Topology LineInteractive | Phase 1phase | Input ports Single, IEC320 C14 | Output power connector type IEC 320 C13 (10A) | Multi-function LCD status and control console
    Kiekis
      Paskutinė prekė

    Išsaugoti prekę Pridėti į palyginimą

    Eaton 5PX 1500i RT2U G2

    Prekė detaliau

    5PX1500IRT2UG2
    1 Vienetas

    Charakteristikos

    Garantija
    24
    Category Code
    UPW
    Unit Box Height
    0.235
    Unit Box Length
    0.59
    Unit Box Width
    0.5
    Vendor Homepage
    www.eaton.com/gb/en-gb/skuPage.5PX1500IRT2UG2.html
    Mounting Type (Desktop/pedestal)
    Yes
    Mounting Type (Rack 2U)
    Yes
    Units per Shipping Box
    1
    Product Net Weight
    22.4 kg
    Unit Calculated Weight
    28.5 kg
    Unit Calculated Volume
    0.069325 cubm
    Output power capacity, W
    1500 Watts
    Output power capacity, VA
    1500 VA
    Wave form type
    Pure sinewave
    Topology
    LineInteractive
    Phase
    1phase
    Input ports
    Single, IEC320 C14
    Output power connector type
    IEC 320 C13 (10A)
    Buttons: (On/Off)
    YES
    LED Displays (Battery charge/Line voltage)
    Yes
    LED Displays (Load)
    Yes
    Multi-function LCD status and control console
    YES

    Greitas palyginimas

    Prekė
    		 Ever SINLINE RT XL 3000 Line-Interactive 3 kVA 3000 W 9 AC outlet(s) APC Smart-UPS SMT1500RMI2UC - 4x C13, USB, Rackmount 2U, SmartConnect, 1500VA
    Prieinamumas
    Kaina
    1 216,57 €
    1 216,93 €
    Aprašymas
    Width
    		 440 mm 432 mm
    Height
    		 132 mm 86 mm
    Depth
    		 630 mm 477 mm
    Weight
    		 42 kg 26.1 kg
    Package height
    		 247 mm 251 mm
    Package width
    		 547 mm 594 mm
    Number of batteries supported
    		 8 1
    Cables included
    		 Input power cable RS-232, USB cable
    Storage relative humidity (H-H)
    		 20 - 95% 0 - 95%
    Manual
    		 Yes Yes
    Operating temperature (T-T)
    		 0 - 40 °C 0 - 40 °C
    Operating relative humidity (H-H)
    		 20 - 80% 0 - 95%
    Storage temperature (T-T)
    		 0 - 45 °C -15 - 45 °C
    Form factor
    		 Rackmount/Tower Rackmount
    USB port
    		 Yes
    LED indicators
    		 Yes Yes
    Battery technology
    		 Sealed Lead Acid (VRLA)
    Battery life (max)
    		 6 year(s)
    Battery capacity
    		 7 Ah
    Battery recharge time
    		 4 h 3 h
    Cooling type
    		 Active
    Output power
    		 3000 W 1000 W
    Input frequency
    		 50 Hz 50/60 Hz
    Output voltage
    		 230 V
    USB 2.0 ports quantity
    		 1
    Response time
    		 10 ms
    Display type
    		 LCD LCD
    Ethernet LAN (RJ-45) ports
    		 1
    Input operation voltage (min)
    		 178 V 151 V
    Power protection features
    		 Short circuit
    Cold start
    		 Yes Yes
    AC outlets quantity
    		 9 AC outlet(s) 4 AC outlet(s)
    Output power capacity
    		 3 kVA 1.5 kVA
    Output operation voltage (max)
    		 253 V 240 V
    Waveform
    		 Sine Sine
    Auto-restart
    		 Yes
    AC outlet types
    		 C13 coupler IEC Jumpers
    Input operation voltage (max)
    		 281 V 302 V
    Audible alarm(s)
    		 Yes
    Battery voltage
    		 12 V
    Output operation voltage (min)
    		 195 V 220 V
    UPS topology
    		 Line-Interactive Line-Interactive
    Typical backup time at full load
    		 3 min
    Automatic Voltage Regulation (AVR)
    		 Yes
    Automatic battery test
    		 Yes
    Typical backup time at half load
    		 7 min
    Number of phases
    		 1
    Surge protection
    		 Yes
    Operating altitude
    		 0 - 1000 m 0 - 3000 m
    International Protection (IP) code
    		 IP20
    Serial interface type
    		 RJ-45
    Quick installation guide
    		 Yes
    Output frequency
    		 50/60 Hz
    Noise Level
    		 46 dB
    Maximum current
    		 16 A
    Surge energy rating
    		 459 J
    Power plug
    		 C20 coupler C14 coupler
    Non-operating altitude
    		 0 - 15000 m
    Product colour
    		 Black Black
    Harmonized System (HS) code
    		 85078000
    Sustainability certificates
    		 Green Premium
    Serial interface
    		 Yes
    Hot-swap battery
    		 Yes
    Total carbon footprint (kg of CO2e)
    		 1416.6
    Audible alarm modes
    		 Alarm when on battery, Low battery alarm
    SmartSlot
    		 Yes
    Emergency Power Off (EPO)
    		 Yes
    Rack capacity
    		 2U
    Resource CD
    		 Yes
    Rack mount kit
    		 Yes
    Number of input phases
    		 1
    Number of output phases
    		 1
    Management card included
    		 No
    Rubber feet
    		 Yes
    Warnings
    		 Do not disassemble the unit housing, there may be a risk of electric shock. Keep away from sources of fire and water.
    SmartConnect port
    		 Yes
