• Gigabitinis interneto tinklo šakotuvas 16-prievadų;
• 16 x 10/100/1000Mbps, metalinis korpusas;
• Auto-MDI/MDIX visiems portams;
• Palaiko CSMA / CD protokolus;
• Atitinka interneto standartus: IEEE 802.3, 10Base-T, IEEE 802.3u, 100Base-TX, IEEE 802.3ab 1000Base-T;
• MAC adresų atmintis: 8k Bitų;
• Maitinimas 100-240V AC, 50/60Hz, 0.2A;
• Išmatavimai: 440(L) x 180(W) x 45 (H) mm.
Techninė charakteristika:
• Hardware Version: Version 4
• 10/100/1000Base-T MDI/MDIX Ports: 16
• Throughput (packet per second): 23.8Mpps
• Switch fabric: 32Gbps / non-blocking
• Weight: 2.30kg
• Power Consumption / Dissipation: 13 Watts / 44 BTU
• Power Requirement: 100-240V AC, 0.6A, 50/60Hz
• Dimension (W x D x H): 440 x 180 x 45 mm, 1U height
• Switch Processing Scheme: Store-and-Forward
• Address Table: 8K entries
• Jumbo packet size: 9K
• Flow Control: Back pressure for half duplex, IEEE 802.3x Pause Frame for full duplex
Standards Conformance
• Regulation Compliance: FCC Part 15 Class A, CE
• Standards Compliance: IEEE 802.3 (Ethernet) IEEE 802.3u (Fast Ethernet) IEEE 802.3ab(Gigabit Ethernet)IEEE 802.3x (Full-duplex flow control)
Environmental Specification
• Temperature: Operating: 0~50 Degree C
• Storage: -40~70 Degree C
• Humidity: Operating: 5~90%
• Storage: 5~90% (Non-condensing)
Now, with the new high port-density Desktop Gigabit Switches from D-Link, upgrading your desktops to Gigabit connections has never been more cost-effective and easier. These desktop Gigabit switches offer an economical way for your workgroup to benefit from the increased bandwidth of Gigabit Ethernet. Each equipped with 16 Gigabit ports, these compact desktop switches provide for fast access to servers to meet your users' increasing network load. With plug-and-play installation and copper Gigabit ports capable of connecting to your existing Cat. 5 twisted-pair cable, these devices instantly enhance your workgroup's performance without requiring you to install expensive fiber cables or to go through complex re-configuration. All ports support 10/100/1000Mbps network speed auto-sensing a
