DAHUA

Switch|DAHUA|Switch type Managed|Switch layer L2|Form factor Desktop|4xRJ-45 ports|RJ-45 Ports Type Fast Ethernet (10/100)|4xFas

83,90 €

Su mokesčiais

The Hardened Cloud Managed PoE Switch series is a state-of-the-art device that can effortlessly turn on and off its managed mode with the simple flip of a switch. When managed mode is enabled, local network management and cloud management are seamlessly integrated. For cloud management, you can perform operation and maintenance using topology visualization for front-end devices, transmission, and back-end storage devices within both security systems and IT system. The switch features a high-performance switch engine and large cache, ensuring smooth transmission of video streams. Additionally, it offers standard PoE for high power consumption, long distance PoE, and PoE Watchdog, simplifying installation and deployment. With its full metal and fanless design, it has great heat dissipation and can operate in harsh environments. It also offers EMC and has protection against overvoltage, overcurrent, static electricity, lightning strikes, pulses and other types of interference. This makes it suitable for scenes such as homes, factories, and offices.

Managed Mode ON/OFF
Easily switches between managed and unmanaged mode with just the flip of a switch. When in managed mode, you can perform management through the webpage locally or the cloud platform. This allows the device to seamlessly adapt to a variety of scenes.

Cloud Management
Devices can be managed through the DoLynk Care app and performs real-time monitoring of the network. The app also displays the status of devices, triggers alarms for errors in real time and sends notifications.

Network Topology Management
Supports the LLDP protocol and is able to generate and display the network topology, so that you can quickly identify issues, and perform operation and maintenance remotely on devices that are in the topology.

Hi-PoE 60W (Orange Port)
In addition to the IEEE802.3af and IEEE802.3at standards, orange port also supports a maximum power output of 60W for powering highpower devices.

Long Distance PoE
The transmission distance of a PoE port can be up to 250 m, meeting the requirement of wired transmission (bandwidth reduced to 10 Mbps).

PoE Watchdog
Adopts the innovative PoE Watchdog. It enables the switch to automatically detect port status and restart the failed ports to recover connection in case of IPC connection exception. This enables intelligent operation and maintenance management in its true sense and effectively reduces manual maintenance costs.

Loop Protection
When a loop is detected, the loop alarm will be triggered and the elimination mechanism will activate to prevent broadcast storms from occurring.

Features managed mode
Complies with IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab and IEEE802.3z standards
Supports network topology visualization
Supports mobile management by app
Supports one-stop maintenance
With its full metal design and dust-proof enclosure, it can be used in a wide range of temperatures
Supports desktop mount and DIN rail mount

Prekė detaliau

Kodas CHS4106-4ET-60

Yra sandėlyje 8 Prekės

Charakteristikos

Garantija: 36
Category Code: SWI
Unit Box Height: 0.08
Unit Box Length: 0.27
Unit Box Width: 0.24
Vendor Homepage: https://transmission.dahuasecurity.com/en/product-list/Business/CloudManagementSolution/NetworkSwitch/CHS4106-4ET-60
Units per Shipping Box: 8
Unit Calculated Weight: 1.05 kg
Unit Calculated Volume: 0.005672 cubm
Summary: Dahua Technology 6-Port Cloud Managed Hardened Switch with 4-Port PoE. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 4. MAC address table: 8000 ent
Weight & dimensions (Weight): 320 g
Weight & dimensions (Width): 110.4 mm
Weight & dimensions (Depth): 154.3 mm
Weight & dimensions (Height): 30 mm
Packaging data (Package width): 239 mm
Packaging data (Package depth): 266 mm
Packaging data (Package height): 77 mm
Packaging data (Package weight): 880 g
Packaging content (Cables included): Power
Design (Product colour): Blue
Design (Housing material): Iron
Power (Power consumption (max)): 65 W
Operational conditions (Operating relative humidity (H-H)): 10 - 90 %
Operational conditions (Operating temperature (T-T)): -30 - 65 C
Operational conditions (Storage relative humidity (H-H)): 5 - 95 %
Operational conditions (Storage temperature (T-T)): -40 - 85 C
Packaging content (Manual): Yes
Design (Form factor): Desktop
Power (Power source): DC
Certificates (Compliance certificates): CE
Performance (Mean time between failures (MTBF)): 1852444.63 h
Design (LED indicators): Yes
Design (International Protection (IP) code): IP30
Management features (Switch type): Managed
Ports & interfaces (Basic switching RJ-45 Ethernet ports quantity): 4
Ports & interfaces (Basic switching RJ-45 Ethernet ports type): Fast Ethernet (10/100)
Ports & interfaces (Fast Ethernet (copper) ports quantity): 4
Ports & interfaces (Uplink ports quantity): 2
Network (10G support): No
Data transmission (Forwarding rate): 3.57 Mpps
Data transmission (MAC address table): 8000 entries
Data transmission (Packet buffer memory): 4 MB
Data transmission (Switching capacity): 4.8 Gbit/s
Design (Rack mounting): No
Power over Ethernet (PoE) (Power over Ethernet (PoE)): Yes
Network (Networking standards): IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3u/IEEE 802.3x/IEEE 802.3z
Data transmission (Jumbo frames): 9216
Data transmission (Jumbo frames support): Yes
Design (DIN rail mounting): Yes
Power (Power supply included): Yes
Management features (Cloud-managed): Yes
Ports & interfaces (Gigabit Ethernet (copper) ports quantity): 1
Design (Reset button): Yes
Management features (Switch layer): L2
Network (Broadcast storm control): Yes
Network (Number of VLANs): 32
Network (Port mirroring): Yes
Network (Virtual LAN features): Port-based VLAN
Network (VLAN support): Yes
Security (DHCP features): DHCP client
Security (Loop protection): Yes
Power over Ethernet (PoE) (Power over Ethernet (PoE) power per port): 30 W
Power over Ethernet (PoE) (Total Power over Ethernet (PoE) budget): 60 W
Management features (Web-based management): Yes
Ports & interfaces (Fiber uplink ports quantity): 1
Ports & interfaces (SFP module slots quantity): 1
Design (IK code): IK06
Design (Suitable for outdoor use): Yes
Power over Ethernet (PoE) (Power over Ethernet (PoE) ports quantity): 4
Packaging data (Terminal block included): Yes
