The indoor/outdoor NanoStation® AC and NanoStation AC loco are compact, high-performance CPEs featuring airMAX® AC technology and a dedicated Wi-Fi radio for management.
Sleek Industrial Design
The NanoStation AC and NanoStation AC loco represent the next evolution of the iconic CPE design that revolutionized the Wireless ISP industry.
Dual Ethernet Connectivity
The NanoStation AC provides a secondary Ethernet port with software-enabled PoE. Use this port to conveniently power an external device, such as a PoE security camera, for seamless IP video integration.
Management Wi-Fi Radio
Each NanoStation AC model integrates a separate Wi-Fi radio for fast and easy setup using your mobile device.
Improved Surge Protection
The NanoStation AC and NanoStation AC loco feature enhanced protection against ESD events.
Now with airOS®8
airOS®8 provides powerful features, including airMAX® ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.
Prekė detaliau
Charakteristikos
- Garantija
- 12
- Category Code
- WAP
- Unit Box Height
- 0.115
- Unit Box Length
- 0.2
- Unit Box Width
- 0.06
- Vendor Homepage
- https://www.ubnt.com/airmax/nanostation-ac/
- Model name
- NanoStation 5AC Loco
- MODEL
- UBIQUITI airMAX NanoStation 5AC Loco
- Units per Shipping Box
- 1
- Unit Calculated Weight
- 0.4 kg
- Unit Calculated Volume
- 0.00138 cubm
- Summary
- Ubiquiti NanoStation 5AC Loco. 5 GHz, Maximum data transfer rate: 1000 Mbit/s, Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White
- Weight & dimensions (Weight)
- 180 g
- Logistics data (Harmonized System (HS) code)
- 85176990
- Weight & dimensions (Width)
- 179 mm
- Weight & dimensions (Depth)
- 77.5 mm
- Weight & dimensions (Height)
- 59.1 mm
- Ports & interfaces (Ethernet LAN (RJ-45) ports)
- 1
- Design (Product colour)
- White
- Power (AC input voltage)
- 24 V
- Certificates (Certification)
- CE, FCC, IC
- Operational conditions (Operating relative humidity (H-H))
- 5 - 95 %
- Operational conditions (Operating temperature (T-T))
- -40 - 70 C
- Power (Input current)
- 0.5 A
- Performance (Operating system installed)
- AirOS
- Design (LED indicators)
- Network/Power/Signal strength
- Performance (Built-in processor)
- Yes
- Performance (Internal memory)
- 64 MB
- Features (5 GHz)
- Yes
- Features (Maximum data transfer rate)
- 1000 Mbit/s
- Power (Power over Ethernet (PoE))
- Yes
- Design (Placement)
- Ceiling
- Antenna (Antenna type)
- Internal
- Features (Ethernet LAN data rates)
- 10/100/1000 Mbit/s
- Features (Frequency band)
- 5.150 - 5.250, 5.250 - 5.350, 5.470 - 5.725, 5.725 - 5.850 GHz
- Features (Maximum outdoor range)
- 10000 m
- Features (Modulation)
- 16-QAM/256-QAM/64-QAM/BPSK/QPSK
- Features (Throughput data rate)
- 450 Mbit/s
