LevelOne GEMINI PTZ IP Network Camera, 2-Megapixel, 20X Optical Zoom, Indoor/Outdoor, IR LEDs, two-way audio, 802.3at PoE

Prekė detaliau

Charakteristikos

Type

IP security camera

Windows operating systems supported

Windows 7

Package type

Box

Width

295 mm

Connectivity technology

Wired

Weight

2 kg

Package depth

384 mm

Package height

218 mm

Package width

218 mm

Package weight

2.2 kg

Power source type

DC, PoE

Operating temperature (T-T)

-30 - 65 °C

Operating relative humidity (H-H)

0 - 90%

Interface

RJ-45

Mounting type

Ceiling

Form factor

Dome

LED indicators

Power

Bluetooth

No

Data transfer rate

16 Mbit/s

Country of origin

China

Sensor type

CMOS

Wi-Fi

No

Compatible memory cards

SD

Maximum memory card size

128 GB

Maximum resolution

1920 x 1080 pixels

Placement supported

Indoor & outdoor

Card reader integrated

Yes

Ethernet LAN (RJ-45) ports

1

FULL HD

YES

Audio output channels

1.0 channels

Cabling technology

10/100Base-T(X)

DC-in jack

Yes

Networking standards

IEEE 802.3at

Ethernet LAN

Yes

Supported graphics resolutions

1280 x 960

Diameter

16.4 cm

International Protection (IP) code

IP66

Ethernet interface type

Fast Ethernet

Video formats supported

AVI

Optical Zoom

20x

Power Over Ethernet (PoE)

Yes

Number of Users

16 user(s)

Quick installation guide

Yes

Quality of Service (QoS) support

Yes

Supported network protocols

TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,SMTP, SNMP, IGMP, 802.1X, QoS, IPv6

Reset button

Yes

Browser supported

Internet Explorer 9+

Password protection

Yes

Frame Rate

60 fps

Product colour

Black

Tilt angle range

-15 - 90°

Harmonized System (HS) code

85258900

Focal length range

4.7 - 94 mm

Web browser

Yes

Products per master (outer) case

4 pc(s)

Master (outer) case gross weight

9.5 kg

Master (outer) case height

460 mm

Master (outer) case length

405 mm

Master (outer) case width

460 mm

Pallet net height

140 cm

Pallet net length

80 cm

Pallet net width

120 cm

LED type

IR

Night vision

Yes

Total megapixels

2 MP

PTZ control

Yes

Optical sensor size

25.4 / 2.8 mm (1 / 2.8")

Field of view (FOV) angle

58.3°

Minimum illumination

0.01 lx

Pan range

0 - 360°

Video compression formats

M-JPEG

DC output voltage

12

Number of cameras

1

Night vision distance

50 m

Number of lenses

1

Day/night mode

Yes

Infrared (IR) cut-off filter

Yes

Built-in HDD

No

Digital Wide Dynamic Range (DWDR)

Yes

Maximum aperture number

3.5

Progressive scan

Yes

Mirror

Yes

Heartbeat

Yes

Anti-flicker

Yes

Digital watermark

Yes

Weatherproof

Yes

Auto flip

Yes

IP address filtering

Yes

Camera shutter speed

1 - 1/10000 s

Privacy masking

Yes

Power consumption (Power over Ethernet (PoE))

20 W

Image quality adjustment

Saturation

Pan speed

80 °/sec

Audio input channels

1.0 channels

Minimum aperture number

1.6

Audio codecs

G.711/G.722/G.726/MP2L2

Tilt preset speed

80 °/sec

Resource CD

Yes
