Greitas palyginimas
Prekė |
Camera DS-2CD1121G2-LIU 2.8mm PL
|
Mini IP valdoma kamera 4MP 25fps, 1/3 colio CMOS sensorius, WIFI
|
|
|
Prieinamumas |
|
|
|
|
Kaina |
67,17 €
|
67,89 €
|
67,91 €
|
68,08 €
|
Aprašymas |
||||
Type |
IP security camera | IP security camera | ||
Package type |
Box | Box | ||
Width |
73 mm | 73 mm | ||
Height |
71 mm | 71 mm | ||
Connectivity technology |
Wired | Wired | ||
Weight |
200 g | 200 g | ||
Package depth |
218 mm | 218 mm | ||
Package height |
103 mm | 103 mm | ||
Package width |
128 mm | 128 mm | ||
Package weight |
360 g | 360 g | ||
Power source type |
DC, PoE | DC, PoE | ||
Storage relative humidity (H-H) |
0 - 95% | 0 - 95% | ||
Manual |
Yes | Yes | ||
Operating temperature (T-T) |
-30 - 60 °C | -30 - 60 °C | ||
Operating relative humidity (H-H) |
0 - 95% | 0 - 95% | ||
Storage temperature (T-T) |
-40 - 60 °C | -40 - 60 °C | ||
Mounting type |
Ceiling/Wall/Pole | Ceiling/Wall/Pole | ||
Form factor |
Bullet | Bullet | ||
Bluetooth |
No | No | ||
Bit rate |
256 Kbps - 4 Mbps | 256 Kbps - 4 Mbps | ||
Length |
174 mm | 174 mm | ||
Sensor type |
CMOS | CMOS | ||
Wi-Fi |
No | No | ||
Signal-to-Noise Ratio (SNR) |
52 dB | 52 dB | ||
Power consumption (max) |
5 W | 5 W | ||
Power consumption (typical) |
1.32 W | 1.32 W | ||
Maximum resolution |
2560 x 1440 pixels | 2560 x 1440 pixels | ||
Placement supported |
Outdoor | Outdoor | ||
Ethernet LAN (RJ-45) ports |
1 | 1 | ||
DC-in jack |
Yes | Yes | ||
Housing material |
Plastic | Plastic | ||
Networking standards |
IEEE 802.3af | IEEE 802.3at | ||
Ethernet LAN |
Yes | Yes | ||
Supported graphics resolutions |
640 x 480 (VGA) | 320 x 240 | ||
International Protection (IP) code |
IP67 | IP67 | ||
Supported video modes |
480p | 240p | ||
Supported network protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS | ||
Password protection |
Yes | Yes | ||
Frame Rate |
30 fps | 30 fps | ||
Mounting kit |
Yes | Yes | ||
Product colour |
White | White | ||
Tilt angle range |
-90 - 90° | -90 - 90° | ||
Sustainability compliance |
Yes | Yes | ||
Fixed focal length |
2.8 mm | 4 mm | ||
Web browser |
Yes | Yes | ||
LED type |
IR | IR | ||
Night vision |
Yes | Yes | ||
Total megapixels |
4 MP | 4 MP | ||
Optical sensor size |
25.4 / 3 mm (1 / 3") | 25.4 / 3 mm (1 / 3") | ||
Minimum illumination |
0.01 lx | 0.01 lx | ||
Pan range |
-90 - 90° | -90 - 90° | ||
Lens viewing angle, diagonal |
106.5° | 88.7° | ||
Video compression formats |
H.264+ | H.264+ | ||
DC output voltage |
12 | 12 | ||
Video motion detection |
Yes | Yes | ||
Number of cameras |
1 | 1 | ||
Night vision distance |
30 m | 30 m | ||
Number of lenses |
1 | 1 | ||
Day/night mode |
Yes | Yes | ||
Infrared (IR) cut-off filter |
Yes | Yes | ||
Lens viewing angle, vertical |
48.9° | 41.5° | ||
Smart IR |
Yes | Yes | ||
Digital Wide Dynamic Range (DWDR) |
Yes | Yes | ||
Region of Interest (ROI) encoding |
Yes | Yes | ||
Maximum aperture number |
2.2 | 2 | ||
Lens viewing angle, horizontal |
88.8° | 75.1° | ||
Infra-red wavelength |
850 nm | 850 nm | ||
Wide Dynamic Range (WDR) |
Yes | Yes | ||
Progressive scan |
Yes | Yes | ||
Mirror |
Yes | Yes | ||
Back Light Compensation (BLC) |
Yes | Yes | ||
Video streaming |
Yes | Yes | ||
IP address filtering |
Yes | Yes | ||
Intelligent Video Surveillance (IVS) system features |
Crossing line | Region exiting detection | ||
Camera shutter speed |
1/3 - 1/10000 s | 1/3 - 1/10000 s | ||
Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) | ||
Privacy masking |
Yes | Yes | ||
Highlight Compensation (HLC) |
Yes | Yes | ||
Number of illumination LEDs |
2 | 2 | ||
HTTPS encryption |
Yes | Yes | ||
Behavior analysis |
Intrusion detection, Line crossing detection, Object removal detection, Region entrance detection, Region exiting detection | Intrusion detection, Line crossing detection, Object removal detection, Region entrance detection, Region exiting detection | ||
Image quality adjustment |
Sharpness | Brightness | ||
Digest authentication |
Yes | Yes | ||
Password reset via email |
Yes | Yes | ||
Number of simultaneous live view channels |
3 channels | 3 channels | ||
Detect distance |
60 m | 80 m | ||
Observe distance |
25 m | 33 m | ||
Recognize distance |
12 m | 16 m | ||
Identify distance |
6 m | 8 m | ||
Human and vehicle targets classification |
Yes | Yes | ||
Compliance certificates |
Federal Communications Commission (FCC) | UKCA | ||
Number of Privacy masking areas |
4 | 4 | ||
Network access storage (NAS) |
Yes | Yes | ||
3D positioning |
Yes | Yes | ||
Warnings |
Avoid direct contact with water to prevent electrical damage. | |||
