Prekė detaliau
Charakteristikos
- Type
- IP security camera
- Width
- 120 mm
- Height
- 198 mm
- Depth
- 172 mm
- Connectivity technology
- Wired & Wireless
- Package depth
- 243 mm
- Package height
- 243 mm
- Package width
- 163 mm
- Package weight
- 1.21 kg
- Power source type
- DC
- Operating temperature (T-T)
- -30 - 60 °C
- Mounting type
- Ceiling/wall
- Form factor
- Turret
- Built-in microphone
- Yes
- Bluetooth
- No
- Bit rate
- 256 Kbps - 4 Mbps
- Noise reduction
- Yes
- Sensor type
- CMOS
- Wi-Fi
- Yes
- Compatible memory cards
- MicroSD (TransFlash)
- Wi-Fi standards
- Wi-Fi 4 (802.11n)
- Maximum memory card size
- 256 GB
- Maximum resolution
- 2560 x 1440 pixels
- Built-in speaker(s)
- Yes
- Placement supported
- Indoor & outdoor
- Card reader integrated
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- Housing material
- Plastic
- Security algorithms
- WPA
- Ethernet LAN
- Yes
- Supported graphics resolutions
- 1920 x 1080 (HD 1080)
- Zoom capability
- Yes
- International Protection (IP) code
- IP66
- Ethernet interface type
- Fast Ethernet
- Supported network protocols
- TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
- Reset button
- Yes
- Password protection
- Yes
- Frame Rate
- 30 fps
- Mounting kit
- Yes
- Product colour
- White
- Tilt angle range
- 0 - 120°
- LED type
- IR
- Night vision
- Yes
- Total megapixels
- 4 MP
- Optical sensor size
- 25.4 / 3 mm (1 / 3")
- Pan range
- 0 - 350°
- Lens viewing angle, diagonal
- 93°
- Video compression formats
- H.264+
- DC output voltage
- 12
- Number of cameras
- 1
- Camera pan control
- Yes
- Camera tilt control
- Yes
- Night vision distance
- 30 m
- Number of lenses
- 1
- Built-in HDD
- No
- Lens viewing angle, vertical
- 43°
- Noise reduction technology
- 3D noise reduction
- Digital Wide Dynamic Range (DWDR)
- Yes
- Lens diameter
- 4 mm
- Lens viewing angle, horizontal
- 79°
- Infra-red wavelength
- 850 nm
- Progressive scan
- Yes
- Mirror
- Yes
- Video streaming
- Yes
- IP address filtering
- Yes
- Intelligent Video Surveillance (IVS) system features
- Human detection
- Privacy masking
- Yes
- Live view
- Yes
- HTTPS encryption
- Yes
- Behavior analysis
- Intrusion detection, Line crossing detection
- Image quality adjustment
- Sharpness
- Digest authentication
- Yes
- Number of simultaneous live view channels
- 3 channels
- Pan speed
- 44 °/sec
- Basic event
- Motion Detection, Camera Tampering Detection, Exception
- Detect distance
- 80 m
- Observe distance
- 33 m
- Recognize distance
- 16 m
- Identify distance
- 8 m
- Tilt speed
- 44 °/sec
- Compliance certificates
- RoHS
