Prekė detaliau
Charakteristikos
- Type
- IP security camera
- Width
- 70.5 mm
- Height
- 66.4 mm
- Depth
- 192.7 mm
- Connectivity technology
- Wired
- Weight
- 610 g
- Package weight
- 770 g
- Power source type
- DC, PoE
- Storage relative humidity (H-H)
- 0 - 95%
- Operating temperature (T-T)
- -40 - 60 °C
- Operating relative humidity (H-H)
- 0 - 95%
- Storage temperature (T-T)
- -40 - 60 °C
- Mounting type
- Ceiling/wall
- Form factor
- Bullet
- Bluetooth
- No
- Sensor type
- CMOS
- Wi-Fi
- No
- Maximum resolution
- 3840 x 2160 pixels
- Placement supported
- Indoor & outdoor
- Ethernet LAN
- Yes
- Product colour
- Black
- Night vision
- Yes
- Total megapixels
- 8 MP
- Number of cameras
- 1
- Built-in HDD
- No
- Cloud-managed
- Yes
Greitas palyginimas
Prekė |
Hikvision DS-2CD2347G2H-LIU(2.8mm)(eF)(O-STD) Turret IP security camera Indoor & outdoor 2688 x 1520 pixels Ceiling
|
|
|
|
Prieinamumas |
|
|
|
|
Kaina |
189,46 €
|
189,71 €
|
190,00 €
|
190,03 €
|
Aprašymas |
||||
Type |
IP security camera | IP security camera | IP security camera | IP security camera |
Width |
102.9 mm | 184 mm | 111 mm | |
Height |
115.4 mm | 32.6 mm | 74 mm | 83.7 mm |
Depth |
65.2 mm | 111 mm | ||
Connectivity technology |
Wired | Wired | Wired | Wired |
Weight |
770 g | 120 g | 525 g | 480 g |
Package depth |
170 mm | 125 mm | ||
Package height |
160 mm | 99 mm | ||
Package width |
170 mm | 150 mm | ||
Package weight |
1.04 kg | 430 g | ||
Power source type |
DC, PoE | DC, PoE | DC, PoE | DC, PoE |
Storage relative humidity (H-H) |
0 - 95% | 0 - 95% | 0 - 95% | 0 - 95% |
Operating temperature (T-T) |
-30 - 60 °C | -10 - 40 °C | -30 - 60 °C | -30 - 60 °C |
Operating relative humidity (H-H) |
0 - 95% | 0 - 95% | 0 - 95% | 0 - 95% |
Storage temperature (T-T) |
-30 - 60 °C | -10 - 40 °C | -40 - 60 °C | -40 - 60 °C |
Mounting type |
Ceiling | Ceiling/wall | Wall | Ceiling |
Form factor |
Turret | Cube | Bullet | Turret |
Built-in microphone |
Yes | Yes | Yes | Yes |
Bluetooth |
No | No | No | No |
Sample rate |
48 kHz | 8 kHz | 8 kHz | |
Bit rate |
32 Kbps - 8 Mbps | 32 Kbps - 16 Mbps | 64 Kbps | |
Noise reduction |
Yes | Yes | Yes | Yes |
Protection features |
Water resistant | |||
Length |
74 mm | |||
Sensor type |
CMOS | CMOS | CMOS | CMOS |
Wi-Fi |
No | No | No | No |
Compatible memory cards |
MicroSDXC | MicroSDXC | MicroSD (TransFlash) | MicroSD (TransFlash) |
Maximum memory card size |
512 GB | 256 GB | 256 GB | 512 GB |
Audio system |
2-way | 2-way | ||
Audio formats supported |
MP3 | MP3 | G.711 | |
Signal-to-Noise Ratio (SNR) |
52 dB | 52 dB | 52 dB | |
Power consumption (max) |
5 W | 5.9 W | 11.5 W | 11.5 W |
Maximum resolution |
2688 x 1520 pixels | 3840 x 2160 pixels | 3840 x 2160 pixels | 3840 x 2160 pixels |
Built-in speaker(s) |
Yes | Yes | Yes | |
Placement supported |
Indoor & outdoor | Indoor | Outdoor | Outdoor |
Card reader integrated |
Yes | Yes | Yes | Yes |
Ethernet LAN (RJ-45) ports |
1 | 1 | 1 | 1 |
Number of languages |
33 | 33 | ||
DC-in jack |
Yes | Yes | ||
Housing material |
Metal | Plastic | Metal | Metal |
Networking standards |
IEEE 802.1x | |||
Security algorithms |
EAP-LEAP | |||
Ethernet LAN |
Yes | Yes | Yes | Yes |
Supported graphics resolutions |
640 x 480 (VGA) | 1920 x 1080 (HD 1080) | 1920 x 1080 (HD 1080) | |
Diameter |
13.8 cm | |||
International Protection (IP) code |
IP67 | IP67 | IP67 | |
Ethernet interface type |
Fast Ethernet | Fast Ethernet | Fast Ethernet | |
Number of Users |
32 user(s) | 32 user(s) | ||
Web-based management |
Yes | Yes | ||
Quality of Service (QoS) support |
Yes | Yes | ||
Supported network protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS | ||
Reset button |
Yes | Yes | Yes | |
Password protection |
Yes | Yes | Yes | |
Languages support |
Multi | |||
Frame Rate |
30 fps | 30 fps | 25 fps | 25 fps |
Mounting kit |
Yes | |||
Product colour |
White | White | White | White |
Tilt angle range |
0 - 75° | 0 - 90° | 0 - 90° | 0 - 85° |
Sustainability compliance |
Yes | |||
Fixed focal length |
2.8 mm | 2.8 mm | 2.8 mm | 4 mm |
Web browser |
Yes | |||
Voice codecs |
G.711alaw | |||
LED type |
IR | IR | IR/White | IR/White |
Night vision |
Yes | Yes | Yes | Yes |
Total megapixels |
4 MP | 8 MP | 8 MP | 8 MP |
Motion sensor |
Yes | |||
Fixed focus |
Yes | |||
Optical sensor size |
25.4 / 1.8 mm (1 / 1.8") | 25.4 / 2.8 mm (1 / 2.8") | 25.4 / 2.7 mm (1 / 2.7") | 25.4 / 2.7 mm (1 / 2.7") |
Minimum illumination |
0 lx | 0 lx | 0.005 lx | 0.005 lx |
Pan range |
0 - 360° | 0 - 360° | 0 - 360° | 0 - 360° |
Dynamic range |
130 dB | 120 dB | 120 dB | |
Lens viewing angle, diagonal |
138.5° | 126.7° | 134° | 109.6° |
Video compression formats |
H.265+ | H.264 | H.264 | H.265 |
Angle of rotation |
360° | 360° | 360° | 360° |
DC output current |
0.41 A | |||
DC output voltage |
12 | 12 | 12 | 12 |
Video motion detection |
Yes | Yes | Yes | Yes |
Number of cameras |
1 | 1 | 1 | 1 |
Camera pan control |
Yes | |||
Camera tilt control |
Yes | |||
Night vision distance |
40 m | 10 m | 30 m | 30 m |
Number of lenses |
1 | 1 | 1 | 1 |
Detection distance |
8 m | |||
Motion sensor technology |
Passive infrared (PIR) sensor | |||
Privacy protection |
Yes | |||
Day/night mode |
Yes | Yes | Yes | Yes |
Infrared (IR) cut-off filter |
Yes | Yes | Yes | Yes |
Built-in HDD |
No | No | No | No |
Lens viewing angle, vertical |
57.6° | 57.9° | 58.8° | 46.1° |
Noise reduction technology |
3D noise reduction | 3D noise reduction | 3D noise reduction | 3D noise reduction |
Smart IR |
Yes | Yes | ||
Region of Interest (ROI) encoding |
Yes | Yes | Yes | Yes |
Maximum aperture number |
1 | 2 | 1.6 | 1.6 |
Lens viewing angle, horizontal |
111.1° | 107.8° | 111.4° | 91.5° |
Number of sensors |
1 | 1 | ||
Infra-red wavelength |
850 nm | 850 nm | 850 nm | 850 nm |
Wide Dynamic Range (WDR) |
Yes | Yes | Yes | Yes |
Progressive scan |
Yes | Yes | Yes | Yes |
Mirror |
Yes | Yes | ||
Heartbeat |
Yes | |||
Digital watermark |
Yes | |||
Back Light Compensation (BLC) |
Yes | Yes | Yes | Yes |
Video streaming |
Yes | Yes | Yes | Yes |
Active tampering alarm |
Yes | |||
IP address filtering |
Yes | Yes | Yes | |
Camera shutter speed |
1/3 - 1/100000 s | 1/3 - 1/100000 s | 1/3 to 1/10000 | 1/3 to 1/10000 |
Bit rate control |
Constant Bit Rate (CBR)/Variable Bit Rate (VBR) | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) | Constant Bit Rate (CBR), Variable Bit Rate (VBR) | Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
Privacy masking |
Yes | Yes | Yes | Yes |
Highlight Compensation (HLC) |
Yes | Yes | Yes | Yes |
Number of illumination LEDs |
2 | 4 | ||
Live view |
Yes | Yes | Yes | |
Power consumption (Power over Ethernet (PoE)) |
6 W | 6.9 W | 12.5 W | |
HTTPS encryption |
Yes | Yes | Yes | |
Behavior analysis |
Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection | Intrusion detection, Line crossing detection | ||
Image quality adjustment |
Contrast | Sharpness | Brightness | Sharpness |
Waterproof connector |
Yes | |||
Lens mount interface |
M16 | |||
Digest authentication |
Yes | |||
Password reset via email |
Yes | |||
Iris |
Yes | |||
Number of simultaneous live view channels |
6 channels | 3 channels | ||
User access level |
Administrator, Operator, User | |||
Built-in light |
Yes | Yes | Yes | |
Detect distance |
61 m | 85.5 m | 85 m | 107 m |
Observe distance |
24 m | 33.9 m | 35 m | 44 m |
Recognize distance |
12 m | 17.1 m | 17 m | 21 m |
Identify distance |
6 m | 8.6 m | 8 m | 11 m |
Pixel counter |
Yes | |||
Human and vehicle targets classification |
Yes | Yes | ||
Client interoperability |
iVMS-4200, Hik-Connect, Hik-Central | |||
Bit rate range |
8 - 320 Kbit/s | |||
Compliance certificates |
RoHS | |||
Number of Privacy masking areas |
4 | 4 | 4 | |
Sample rates |
8 - 48 kHz | |||
Automatic Network Replenishment (ANR) |
Yes | |||
Network access storage (NAS) |
Yes | |||
Warnings |
Avoid direct contact with water to prevent electrical damage. | The product contains electronic components; do not dispose of with the normal household waste. | ||
Audit log |
Yes | |||
